Newtonite 803 Lath Mesh Membrane 20m2

Newtonite Lath Mesh Membrane – High-Performance Damp Proofing Solution

Newtonite Lath Mesh Membrane is a high-density polyethylene (HDPE) damp proof membrane with a heat-welded, rot-proof polythene mesh. Designed for superior adhesion, it creates a mechanical key for plasters, renders, and dot & dab plasterboard, providing long-lasting protection against moisture ingress.

Key Benefits

• Effective Damp Proofing – Completely separates the wall surface from dampness, ensuring no moisture or salt damage.
• Strong Mechanical Key – The meshed surface provides excellent adhesion for plastering and rendering.
• No Chemical DPC Required – Eliminates the need for injected damp-proof courses.
• Fast & Easy Installation – Lightweight and easy to cut with a knife, scissors, or shears.
• Minimal Surface Preparation – Can be installed over existing render without additional damage.
• Durable & Reliable – Guaranteed against deterioration for 30 years with a 50+ year life expectancy.

Typical Applications

• Damp-proof base for plasters, renders, or dot & dab plasterboard.
• Rising damp protection for internal walls in homes and commercial properties.

Product Variants & Codes

• 1.0m x 10m Roll – Code: M16
• 1.2m x 10m Roll – Code: M9
• 1.0m x 20m Roll – Code: M21
• 2.0m x 20m Roll – Code: M22

Technical Specifications

• Material: High-density polyethylene (HDPE)
• Colour: White/Translucent
• Thickness at 100 kPa: 2.64mm
• Water Vapour Resistance (Sd value): >604m
• Thermal Conductivity: 0.461 W/mK
• Fire Resistance: Euroclass E
• Chemical & Oxidation Resistance: Excellent

Newton Waterproofing Systems, established in 1848, is a trusted leader in damp proofing solutions, offering reliable and industry-proven products for modern and heritage buildings.

Technical Data

Downloads

•  Download Newtonite Lath Data sheet

•  Download Newtonite Lath DoP
