Above-slab drainage conduit that is designed to capture water that is entering properties via the wall/floor junction for removal to an appropriate drainage medium.
Key Benefits
Newton CDM BaseBoard is a patented US product only available in the United Kingdom from Newton Waterproofing Systems
Typical Applications
Prior to installing the Newton CDM Baseboard System, mechanically fix a Newton cavity drain membrane to the retaining wall. Apply Newton CDM MultiPlugs at 1m centres and affix the CDM Baseboard Hanger in the head of the plug.
The CDM Baseboard is then clipped tight over the hanger to hold the linear lengths of the conduit into position. Use the CDM Baseboard jointing pieces to form a continuous length of the conduit. Apply an epoxy band of 150mm to the wall floor junction fillet as a key for the Newton One Shot Adhesive.
The waterproof bond between the One Shot and the epoxy allows for ingressing water to travel within the CDM Baseboard to a predetermined drainage outlet for removal.
Newton CDM Baseboard preformed internal and external corners and stop-ends are also required.
Technical Data
| Features | Result |
| Baseboard Pack | 1 x 2.0m length |
| Total linear coverage per pack | 2.0m |
| Pack supplied with | 3 hangers, 1 connector, 3 adhesives |
| Weight per pack | 6.00kg |
| Colour | White |
| Raw material | UPVC |
Downloads
|
D9 CDM Baseboard Outside Corner Colour: White |
D10
CDM Baseboard Inside Corner Colour: White |
D11R & D11L
CDM Baseboard End Caps (Right/Left) Colour: White |
|
D12
CDM Baseboard Length 2.4m Colour: White |
D12H
CDM Baseboard Hanger Colour: White |
D13
CDM Baseboard Connector Colour: White |
