Description
Mapei Esterflex SBS – SBS Modified Bitumen Torch-On Roofing Membrane
Available in Mineral Cap Sheet, Sanded Cap Sheet and Underlay Options.
Mapei Esterflex SBS is a high-performance elastomeric bitumen waterproofing membrane designed for flat roofing and refurbishment applications. Modified with SBS (Styrene-Butadiene-Styrene) elastomeric resin, it provides flexibility at low temperatures, good dimensional stability and reliable waterproofing performance.
The range includes mineral and sanded cap sheets, together with an underlay membrane for built-up roofing systems. The mineral cap sheet features a slate chippings finish for exposed roof applications, while the underlay is protected by Polyflam film on both sides to provide a bitumen-rich surface during torch-on installation.

Key Features and Benefits
- SBS elastomeric bitumen: Provides flexibility and reliable waterproofing performance.
- Low-temperature flexibility: Flexible down to -15°C.
- Torch-on application: Designed for heat-applied installation.
- Reinforced construction: Provides dimensional and mechanical stability.
- Mineral finish: Slate chippings provide a protective exposed surface.
- Polyflam film: Heat-fusible protective film on the underside of the cap sheets.
- Underlay option: Polyflam protection on both sides for use within compatible built-up roofing systems.
- 10-year product warranty: As stated in the manufacturer product data sheet.
Applications
- Flat roof waterproofing systems.
- Built-up bituminous roofing systems.
- New-build roofing projects.
- Refurbishment overlays on existing asphalt.
- Overlays on selected existing bitumen membranes.
- Commercial, industrial and residential roofing projects.
When used for refurbishment, the existing roof build-up must be checked to ensure it is suitable, stable and properly bonded before installation.
Esterflex SBS Product Options
Esterflex SBS Mineral Cap Sheet
Polyester-reinforced SBS modified bitumen membrane with a slate chippings finish. Designed as an exposed cap sheet within suitable roofing systems. Features a lateral selvedge to assist with overlapping during installation.
Esterflex SBS Sanded Cap Sheet
Polyester-reinforced SBS modified bitumen membrane with a sanded surface finish. Suitable for applications where a sanded finish is specified within the roofing build-up.
Esterflex SBS Underlay
Underlay membrane protected by Polyflam film on both sides. Designed for use beneath a compatible cap sheet, providing a bitumen-rich surface during torch-on application.
Technical Specifications
- Product Type: SBS modified elastomeric bitumen membrane.
- Application: Torch-on.
- Cap Sheet Reinforcement: Polyester.
- Underlay Reinforcement: Glass fibre.
- Low-Temperature Flexibility: -15°C.
- Cap Sheet Roll Width: 1 metre.
- Underlay Roll Width: 1 metre.
- Mineral Cap Sheet Roll Length: 8 metres.
- Sanded Cap Sheet Roll Length: 8 metres.
- Underlay Roll Length: 15 metres.
- Mineral Cap Sheet Weight: Approximately 4.5 kg/m².
- Sanded Cap Sheet Weight: Approximately 4.0 kg/m².
- Underlay Weight: Approximately 2.4 kg/m².
- Warranty: 10-year product warranty, subject to applicable manufacturer terms.
Technical information is taken from the Mapei Esterflex SBS product data sheet. Always consult the current manufacturer documentation for installation requirements and system suitability.
Installation Guidance
Esterflex SBS membranes are designed for professional torch-on installation. The substrate must be suitably prepared, dry, clean and free from loose material or contamination. Primer selection, membrane overlaps, detailing and installation procedures must follow the manufacturer's instructions.
Torch-applied roofing involves the use of an open flame and must only be carried out by suitably trained and competent installers using appropriate fire precautions and safe working procedures.
Frequently Asked Questions
1. What is Mapei Esterflex SBS?
Esterflex SBS is an SBS elastomeric bitumen waterproofing membrane designed for torch-on flat roofing and refurbishment applications.
2. What is the difference between the cap sheet and underlay?
The cap sheet provides the upper waterproofing layer and is available with mineral or sanded finishes. The underlay is designed to sit beneath a compatible cap sheet within a built-up roofing system.
3. What temperature can Esterflex SBS withstand?
The manufacturer data sheet states low-temperature flexibility down to -15°C. This is a flexibility test value, not a stated continuous operating temperature range.
4. Can Esterflex SBS be used for roof refurbishment?
Yes. It is suitable for certain refurbishment overlays on existing asphalt and selected bitumen membranes, provided the existing roof build-up is checked and suitably prepared.
5. Is Esterflex SBS torch applied?
Yes. The membrane is designed for torch-on installation using appropriate professional roofing techniques and fire precautions.
6. What is the warranty period?
The manufacturer product data sheet states a 10-year product warranty. Applicable conditions and any system requirements should be checked with the manufacturer.
7. What roll sizes are available?
The manufacturer data sheet lists 8m rolls for the cap sheets and 15m rolls for the underlay. All listed rolls are 1m wide.
