Description
Mapei Mapeheat Membrane Maxi – Lightweight Waterproofing, Uncoupling and Anti-Fracture Membrane
Mapei Mapeheat Membrane Maxi is a lightweight, 7mm-thick uncoupling, anti-fracture and waterproofing membrane developed for electric underfloor heating systems. Its specially designed surface incorporates reliefs that accommodate heating cables, allowing them to sit securely and remain flat beneath the finished floor covering.
Suitable for heating cables between 2mm and 5.5mm in diameter, Mapeheat Membrane Maxi helps prevent the transmission of in-plane substrate cracks up to 3mm wide. Its low-profile construction and minimal roll memory help simplify installation, making it particularly useful for renovation projects where maintaining floor height is important.
The polypropylene membrane is suitable for internal flooring installations beneath ceramic, porcelain and natural stone tiles. It can also receive a suitable smoothing compound before the installation of engineered wood, luxury vinyl tiles, luxury vinyl planks, laminate and mosaic flooring, subject to the manufacturer's installation requirements.

Key Benefits
- Lightweight polypropylene membrane for electric underfloor heating.
- 7mm-thick profile for reduced floor build-up.
- Suitable for heating cables between 2mm and 5.5mm in diameter.
- Helps prevent transmission of in-plane substrate cracks up to 3mm wide.
- Heating cables sit securely within the membrane reliefs.
- Minimal roll memory helps achieve a flatter installation.
- Suitable for ceramic, porcelain and natural stone floor coverings.
- Can receive smoothing compound for specified alternative floor finishes.
- Helps inhibit mould growth.
Suitable Applications
- Electric underfloor heating installations.
- Internal bathrooms, kitchens and living areas.
- New flooring installations and renovation projects.
- Installation beneath ceramic, porcelain and natural stone tiles.
- Flooring installations using engineered wood, luxury vinyl, laminate and mosaic, with the appropriate smoothing compound and preparation.
Waterproofing Information
Mapeheat Membrane Maxi is described by Mapei as a waterproofing membrane. However, for ceramic tile installations where waterproofing is required, Mapei provides an additional waterproofing procedure using Mapeguard WP Adhesive and Mapeguard ST or Mapeband Easy jointing tape at the membrane seams and wall junctions.
Waterproofing detailing must follow the manufacturer's instructions. Mapeheat Membrane Maxi must not be used for submerged applications, floors subject to standing water or external installations.
Installation Overview
- Prepare a smooth, mechanically sound and suitably dry substrate, free from contamination that could affect adhesion.
- Select an appropriate Mapei C2-classified adhesive for bonding the membrane.
- Cut and dry-fit the membrane before installation.
- Apply the adhesive and install the membrane with the fabric side facing down.
- Align adjoining sheets carefully, ensuring the reliefs match and the sheets do not overlap.
- Use a weighted roller or suitable tool to ensure full contact with the adhesive.
- Install the compatible Mapei heating cable in accordance with its own technical instructions.
- Complete the selected floor covering installation using the appropriate Mapei products and procedures.
For alternative floor coverings such as engineered wood, luxury vinyl and laminate, Mapei specifies a suitable smoothing compound. Its UK TDS identifies Ultraplan Renovation Screed 3240 at a minimum thickness of 6mm above the highest point of the membrane, subject to the requirements of the chosen floor covering.
Technical Data
- Product: Mapeheat Membrane Maxi.
- Material: Polypropylene.
- Colour: Blue.
- Thickness: 7mm.
- Width: 1m.
- Available roll lengths: 5m and 15m.
- Membrane weight: 820g/m².
- Heating cable compatibility: 2mm to 5.5mm diameter.
- Crack isolation: Helps prevent transmission of in-plane substrate cracks up to 3mm.
- Application temperature range: +5°C to +40°C.
- Recommended adhesive: Mapei C2-classified adhesive, selected for the application.
Important Application Restrictions
- For internal applications only.
- Do not use in submerged applications or on floors subject to standing water.
- Do not use externally.
- Do not install over structural expansion joints.
- Do not use over cracks or control joints subject to out-of-plane movement.
- Do not use where in-plane movement exceeds 3mm.
- Do not install directly over bituminous substrates.
- Do not use with solid hardwood flooring.
- Do not use tiles smaller than 5cm x 5cm.
- Follow Mapei's additional requirements for mosaic and moisture-sensitive floor coverings.
Frequently Asked Questions
What is Mapeheat Membrane Maxi used for?
It is a lightweight uncoupling, anti-fracture and waterproofing membrane designed for electric underfloor heating installations beneath suitable floor coverings.
What size heating cables does it accommodate?
The membrane is designed to accommodate electric heating cables between 2mm and 5.5mm in diameter.
How thick is Mapeheat Membrane Maxi?
The manufacturer's UK technical data sheet specifies a thickness of 7mm.
Can Mapeheat Membrane Maxi help prevent floor tile cracking?
It helps prevent the transmission of in-plane substrate cracks up to 3mm wide. It must not be used to bridge structural expansion joints or cracks subject to out-of-plane movement.
Does Mapeheat Membrane Maxi provide waterproofing?
It is described as a waterproofing membrane, but where waterproofing is required beneath ceramic tiles, Mapei specifies additional seam and perimeter detailing using Mapeguard WP Adhesive and compatible jointing tape.
Can it be used with vinyl or laminate flooring?
Yes, it can receive a suitable smoothing compound before installation of specified alternative floor coverings, including luxury vinyl and laminate. Follow the minimum smoothing compound thickness and floor covering manufacturer's requirements.
Technical Documentation
Refer to the manufacturer's technical data sheet for complete installation instructions, substrate requirements, waterproofing details and application restrictions.
Supply from Clever Shield Coatings UK
Clever Shield Coatings UK supplies Mapei waterproofing and construction products throughout the UK. For technical suitability, installation requirements and compatible system components, always refer to the current manufacturer's documentation.
