Description
RIW Gas Seal Blue Gas Barrier & Damp Proof Membrane
RIW Gas Seal Blue is a high-performance three-layer polyethylene gas barrier and damp proof membrane designed to protect buildings against moisture, radon, low-level methane and carbon dioxide. Reinforced with a polypropylene grid for added strength and durability, it provides combined gas protection and damp proofing in a single membrane, eliminating the need for a separate DPM in many applications. Suitable for use beneath ground-bearing concrete slabs and above suspended beam and block floors, Gas Seal Blue delivers reliable long-term protection for residential, commercial and industrial construction projects.
Manufactured from virgin polyethylene rather than recycled materials, the membrane offers outstanding tensile strength, puncture resistance and dimensional stability. The distinctive blue and white construction provides simple on-site quality control, while its comprehensive sealing system ensures airtight lap joints and continuity throughout the building envelope. Gas Seal Blue is BBA Approved and complies with the latest guidance from BS 8485, BRE and CIRIA for gas protection systems.
Key Benefits
- Combined gas barrier and damp proof membrane
- Protects against radon, methane and carbon dioxide
- Prevents moisture and water vapour ingress
- Three-layer reinforced polyethylene construction
- Manufactured from virgin material
- Separate damp proof membrane not normally required
- High tensile and tear resistance
- Robust joint sealing system
- Weldable membrane
- Blue and white layers for quality control
- Suitable for suspended and ground-bearing floors
- BBA Approved
- CE Marked to EN 13967
Applications
- Gas protection systems
- Ground floor damp proof membranes
- Radon barrier systems
- Methane protection
- Carbon dioxide protection
- Ground-bearing concrete slabs
- Suspended beam and block floors
- Precast concrete floors
- Residential construction
- Commercial developments
- Industrial buildings
Technical Information
- Product Type: Reinforced polyethylene gas barrier membrane
- Material: Three-layer LDPE with polypropylene reinforcing grid
- Colour: Blue / White
- Thickness: 0.5mm
- Roll Size: 2m × 50m
- Coverage per Roll: 100m²
- Weight: 275g/m² (27.5kg per roll)
- Lap Width: 150mm
- Tensile Strength:
- MD: 500N/50mm
- CD: 470N/50mm
- Radon Permeability: 1.5 × 10⁻¹¹ m² s⁻¹ Pa⁻¹
- Methane Permeability: 1.92 × 10⁻¹⁷ m² s⁻¹ Pa⁻¹
- Carbon Dioxide Permeability: 1.64 × 10⁻¹⁶ m² s⁻¹ Pa⁻¹
- Standard: EN 13967
- Certification: BBA Approved & CE Marked
Frequently Asked Questions
What is RIW Gas Seal Blue used for?
It provides combined damp proofing and protection against radon, methane and carbon dioxide beneath concrete floors.
Can it replace a damp proof membrane?
Yes. Gas Seal Blue functions as both a gas barrier and damp proof membrane, removing the need for a separate DPM in many applications.
Where can it be installed?
It is suitable beneath ground-bearing reinforced concrete slabs and above suspended beam and block or precast concrete floors.
How are joints sealed?
Adjacent sheets should overlap by 150mm and be sealed using RIW Gas Seal Tape and Lap Tape to maintain an airtight gas barrier.
Is RIW Gas Seal Blue certified?
Yes. It is BBA Approved and CE Marked to EN 13967 for use as a gas barrier and damp proof membrane.
