Description
Structural Frame Insulation Foam for Windows & Glazing Systems
Soudatherm SFI 600P is a professional polyurethane foam designed for filling, sealing and strengthening cavities between glazing units and window frames. Developed for structural frame insulation applications, it enhances airtightness, thermal performance and mechanical stability in modern window and door systems. It is compatible with aluminium, PVCu, timber and composite frame constructions, as well as most insulating glass unit (IGU) sealants.
The low-expansion foam provides controlled application and excellent insulation performance, helping to improve window Uf-values while reducing air leakage and enhancing acoustic insulation. Applied using an adjustable gun system, it offers fast curing with skin formation in approximately 10 minutes and full cure after 24 hours.
Key Features & Benefits
- Professional polyurethane structural frame insulation foam
- Designed for glazing rebate filling applications
- Improves airtightness around windows and doors
- Enhances thermal performance and Uf-values
- Improves acoustic insulation
- Enhances mechanical stability of window systems
- Controlled expansion rate
- Low expansion formulation
- Fast curing
- Skin formation in approximately 10 minutes
- Full cure after approximately 24 hours
- Compatible with most IGU sealants
- Excellent adhesion to PVCu, aluminium and timber
- Easy to cut if glazing units require replacement
- No flammable propellants
- Professional gun-applied system
Suitable Applications
- Window frame cavity filling
- Structural frame insulation
- Glazing rebate filling
- Window manufacturing
- Window installation projects
- Door frame insulation
- Air leakage reduction around glazing
- Thermal performance improvements
- Acoustic insulation around frames
- Commercial glazing systems
- Residential window installations
Suitable Materials
- PVCu window frames
- Aluminium window frames
- Timber window frames
- Composite frame systems
- Glass units
- Most IGU secondary sealants
- Metal profiles
Technical Information
- Base: Polyurethane foam
- Application Method: Adjustable gun system
- Skin Formation Time: Approximately 10 minutes
- Full Cure Time: Approximately 24 hours
- Thermal Conductivity: 0.036 W/m.K
- Expansion Rate: Controlled low expansion
- Acoustic Insulation Enhancement: Yes
- Airtightness Improvement: Yes
- UV Exposure: Not suitable for exposed applications
- Compatible with IGU Sealants: Yes
- No Flammable Propellants: Yes
Frequently Asked Questions
What is Soudatherm SFI 600P used for?
It is designed to fill, seal and strengthen the cavity between glazing units and window frames, improving airtightness, insulation performance and structural stability.
What frame materials is it compatible with?
Soudatherm SFI 600P adheres to PVCu, aluminium, timber and other common window frame materials.
Does it improve window insulation performance?
Yes. The foam helps improve airtightness, acoustic insulation and thermal performance, with a thermal conductivity of 0.036 W/m.K.
How quickly does the foam cure?
Skin formation occurs within approximately 10 minutes, with full cure achieved after around 24 hours.
Can the cured foam be exposed to sunlight?
No. The cavity and cured foam should not be exposed to UV radiation and should remain protected within the frame system.
Is it compatible with insulating glass unit sealants?
Yes. It is compatible with most IGU secondary sealants used in window manufacturing and glazing systems.
