TECNOFOAM G-2008 Plus Spray Insulation Foam

TECNOFOAM G-2008 PLUS

Open Cell

Spray polyurethane foam (SPF) system for thermal and acoustic insulation(applied density ±8 kg/m³)

It is a water-based spray polyurethane open-cell foam system (SPF) for and thermal and acoustic insulation, is specifically formulated to apply low-density foam (8~10 kg/m³). Its application must be carried out by the specific reactor equipment by mixing Tecnofoam G-2008 PLUS (polyol side) and Tecnofoam G-2049.I (isocyanate side). The blowing agent is water.

It has CE marking on the basis of a statement made DoP Declaration of Performance (DoP) under the European Norm EN-14315-1:2031.

CE CertifiedE Euro ClassFree of HFC's and HCFC'sWater Based Spry Insulation Foam
Uses

For application in the following situations:

Thermal insulation systems in residential buildings, businesses or industries
Indoor applications ceilings, interior chambers facade, internal side of roofs, made with wood structure, or other material (see compatibility).

NOTE: call our technical department about the application to other supports or situations 0800 7022176

Applied density ±8 kg/m³
Thermal conductivity 0,038 W/m·K
Cream/stirring time 2~6 secs
Gel time 6~10 secs
Tack-free time 10~14 secs
Fire reaction Euroclass E
Close-cell content <20% (CCC1)
Application Spray equipment

General Specifications

It is an open-cell spray polyurethane foam (SPF), for thermal and acoustic insulation, easy to apply and to protect all the internal surfaces of the building
The application and training is done by our spray equipment TC2049 (spray-equipment.tecnopolgroup.com) or similar.

The blowing agent is water. It is free from the harmful to the ozone layer, so it does not promote the greenhouse effect (NOT contain HFCs, HCFCs, VOCs, etc ...); it does not emit any substance to the environment once installed. The applied system is 100% recyclable by mechanical means friendly to the environment. No gas collection for recycling and/or destruction is required.

The properties of the polyurethane foam system allow it to adhere to any surface such as concrete, ceramic, metal, polyurethane foam, wood, acrylic paints (checking the situation of areas recommended).

It forms a continuous coat without joints preventing the formation of "heat bridges" and providing an optimum thermal insulation surface with high thermal insulation parameters.

Foam applied without allowing for cooling may result in excess heat build-up and result in fire or the generation of offensive odors that may not dissipate with time.
The thermal conductivity coefficient remains unchanged from the application and along with the product life.

It is free from harmful to the ozone layer, so do not promote the greenhouse effect (NOT contain HFCs, HCFCs, VOCs, etc ...); it does not emit any substance to the environment once installed. It is a system 100% recyclable by mechanical means friendly to the environment, and no gas collection for recycling and/or destruction is required.

Contractors and applicators must comply with all applicable and appropriate guidelines for processing, handling guidelines and local rules and norms.
It is regulated under the European standard EN 14315-1: 2013 "Thermal insulating products for applications in buildings, rigid polyurethane foam (PUR) products", for which it has CE marking based on a DoP Declaration of Performance.

Yield

The performance is around 1kg/m² at 10 cms of thickness.

Packaging

Metal drums of 215 kg for the polyol, and 250 kg for the isocyanate.
