CARBOPLATE High-Strength Carbon Fibre Plate 15kg

CARBOPLATE – High-Strength Carbon Fibre Plate for Structural Reinforcement

CARBOPLATE is a pultruded carbon fibre plate engineered for the structural strengthening of concrete, steel and masonry elements. Protected with a plastic film on both sides, it delivers exceptional tensile strength, durability and lightweight performance, making it ideal for structural reinforcement in civil, industrial and infrastructure projects.

Where to Use

• Flexural and shear strengthening of beams and slabs
• Reinforcing concrete, steel or masonry structures
• Strengthening bridges, tunnels, buildings and viaducts
• Use in seismic upgrades and repairs of damaged structures

Key Features

• High modulus of elasticity: 170, 200 or 250 GPa
• Excellent tensile strength: Up to 3,300 MPa
• Lightweight and corrosion-resistant
• Protected with plastic film on both faces
• Pultruded carbon fibre for consistent quality and performance
• Elongation at failure: 2%, 1.4% or 0.9%, depending on type
• Available widths: 50 mm, 100 mm and 150 mm
• Thickness: 1.4 mm
• Resistant section: 70, 140 or 210 mm²

Packaging

Supplied in 25 m rolls, with various widths available.

CARBOPLATE provides a high-strength, low-weight reinforcement system that enhances load capacity and extends the lifespan of critical structural elements.

Frequently Asked Questions

1. What is CARBOPLATE used for?

CARBOPLATE is a carbon fibre plate used for structural strengthening and reinforcement of concrete, steel and masonry elements, including beams, slabs, bridges and buildings.

2. Can CARBOPLATE strengthen existing concrete structures?

Yes. It is designed for structural reinforcement applications, including flexural and shear strengthening of existing concrete beams and slabs.

3. What widths are available?

CARBOPLATE is available in widths of 50 mm, 100 mm and 150 mm, with a stated thickness of 1.4 mm.

4. What is the tensile strength of CARBOPLATE?

The stated tensile strength is up to 3,300 MPa. The mechanical properties vary depending on the selected plate type.

5. Is CARBOPLATE suitable for bridges and infrastructure?

CARBOPLATE is intended for structural strengthening applications in bridges, tunnels, buildings and viaducts. Suitability for a particular project must be assessed by the responsible structural engineer.
