Newcoat 701-HB (Graphite Grey) Epoxy High Build Waterproofing bund lining, Concrete Floor Coating, epoxy coating, Epoxy

Roll over image to zoom in Click on image to zoom

Newton Newcoat 701-HB (Graphite Grey)

Name: Newton Newcoat 701-HB (Graphite Grey)
Brand: Newton Waterproofing
SKU: 701-hb
Price: 73.79 GBP
Availability: InStock
Rating: 5 (11 reviews)

Save £19.61

Newton WaterproofingSKU: 701-HB

Size: 5KG

Color: Grey

Variant

Price:

£73.79 £93.40

VAT included / Shipping calculated at checkout

Quantity:

💳 Pay in Instalments - Just choose Shop Pay at checkout!

🚚 Next-day and Express delivery options are available at checkout.

Share this product

Epoxy High Build Coating – Durable & Chemical-Resistant Protection

The Epoxy High Build Coating is a two-component, solvent-free epoxy resin-based coating designed for protecting and enhancing concrete, steel, and other substrates. This high-performance coating offers exceptional chemical resistance, durability, and a fully sealed hygienic surface, making it ideal for industrial, commercial, and food-grade environments.

Once mixed, the self-priming formulation provides a tough, abrasion-resistant finish, suitable for heavy-duty applications such as chemical bunds, manufacturing areas, and warehouses.

Key Benefits

✔ Solvent-free, low odour – Safe for use in enclosed spaces.
✔ Excellent adhesion – Bonds securely to concrete and steel surfaces.
✔ Waterproof & Chemical-Resistant – Protects against oils, chemicals, and water exposure.
✔ Tough & Abrasion-Resistant – Withstands heavy-duty use in industrial settings.
✔ Easy to apply – Provides a smooth, high-build finish.
✔ Hygienic & Easy to Clean – Ideal for food preparation areas & hygienic environments.

Typical Applications

🔹 Industrial & Commercial Flooring – Tough, durable surface for high-traffic areas.
🔹 Food & Beverage Facilities – Suitable for breweries, bottling factories, and food prep areas.
🔹 Chemical & Oil Storage – Protective coating for bunds, tanks, and containment areas.
🔹 Warehouses & Manufacturing – Provides a sealed, chemical-resistant finish.
🔹 Aircraft Hangars & Abattoirs – Heavy-duty protection for high-impact environments.

Product Data

Code	Packaging	Colour	Application Rate (2 Coats)
701-HB	5kg	Grey (Part A), Milky White (Part B)	0.5-0.6 kg/m²

Downloads

Download NewCoat 701-HB Data Sheet

Download NewCoat 701-HB Safety Data Sheet

Download NewCoat 701-HB Declaration of Performance

Download NBS Clause

Technical Data

Cured Performance	Result
Colour	Grey or Red
Membrane thickness – First coat over primer	0.15mm
Membrane thickness – Further protective coats	0.15mm
Adhesion to concrete (>B2.0)	3.5 MPa
Impact resistance – Class 2	14 Nm
Abrasion resistance	AR 0.5
Resistance to dilute acid/alkaline	Excellent
Shore Hardness – D	82
Slip resistance*	+45 PTV
Reaction to fire classification – Not determined	Euroclass F

*Slip resistant variant is standard to Carmine Red only unless by special order
