Description
Visqueen Radon R400 Membrane – Radon & Damp Proof Protection Membrane
The Visqueen Radon R400 Membrane is a high-performance 0.4mm (1600 gauge) thermoplastic membrane designed to prevent the ingress of radon gas while also acting as an effective damp proof membrane (DPM).
Manufactured from virgin polymer, this flexible and durable membrane is suitable for use in both basic and full radon protection systems, delivering long-term protection in modern construction.
Key Features & Benefits:
✔ Radon Protection – Prevents ingress of harmful radon gas
✔ Dual Purpose – Functions as both radon barrier and damp proof membrane
✔ BBA Certified – Third-party accredited for performance and reliability
✔ 1600 Gauge Thickness – Meets radon membrane standards
✔ Flexible Installation – Can be taped or heat welded
✔ Durable & Strong – Resistant to tearing, impact, and site conditions
✔ Standards Compliant – Conforms to BR 211:2023 guidance
Ideal Applications:
✔ Radon protection systems (basic & full protection areas)
✔ Ground floor construction (above or below slab)
✔ Beam and block flooring systems
✔ Concrete slab installations
✔ Residential and commercial buildings
Installation Guidelines:
Install on a smooth, clean, and level substrate
Lay membrane loose and ensure it is clean and dry before jointing
Seal joints using:
- 150mm overlap (taped)
- 100mm overlap (heat welded)
Seal all penetrations using top hat units or detailing strips
Protect membrane after installation to avoid UV and site damage
⚠ Not suitable where hydrostatic pressure is present
⚠ Do not install below 5°C
Product Specifications:
Thickness: 0.4mm (1600 gauge)
Roll Size: 4m x 20m
Material: Thermoplastic (virgin polymer)
Colour: Red
Installation: Loose laid, taped or welded joints
Standards & Compliance:
BBA Certified (13/5069)
Conforms to BR 211:2023
EN 13967:2017 compliant
ISO 9001 / 14001 / 45001 certified manufacturing
Frequently Asked Questions
What is Visqueen Radon R400 used for?
It is used to prevent radon gas ingress and also acts as a damp proof membrane.
Can it be used above and below slabs?
Yes, it can be installed above or below the structural floor.
How are joints sealed?
Joints can be taped (150mm overlap) or heat welded (100mm overlap).
Does it provide damp protection as well?
Yes, it functions as a combined radon barrier and DPM.
Does it meet UK building standards?
Yes, it is BBA certified and compliant with BR 211:2023.
