Description
RIW Structureseal Pre-Applied Bentonite Waterproofing Membrane
RIW Structureseal is a premium pre-applied waterproofing membrane designed to protect below-ground concrete structures from water ingress. Manufactured from a high-strength geotextile composite encapsulating natural sodium bentonite, it forms a durable waterproof barrier that bonds directly to concrete and self-seals around minor cracks caused by settlement or shrinkage. Suitable for new-build basements, retaining walls, foundation slabs and boundary line construction, Structureseal delivers long-term waterproofing performance for Type A waterproofing systems in accordance with BS 8102.
When exposed to water, the sodium bentonite expands to create a dense, monolithic waterproof layer capable of resisting hydrostatic pressure while preventing water migration between the membrane and the structure. Its pre-applied design requires no primers or adhesives, allowing fast installation in a wide range of weather conditions. Structureseal is BBA Approved and suitable for use beneath reinforced concrete slabs, against retaining walls, piling systems and other below-ground concrete applications where reliable waterproofing is essential.
Key Benefits
- Pre-applied bentonite waterproofing membrane
- BBA Approved waterproofing system
- Forms a permanent bond with concrete
- Self-seals around small cracks and minor movement
- Suitable for wet weather installation
- No primers or adhesives required
- Resistant to hydrostatic water pressure
- Suitable for Type A waterproofing systems
- Quick and easy installation
- Ideal for basements, foundations and retaining walls
- Zero VOC formulation
- Long-term waterproof protection
Applications
- Basement waterproofing
- Foundation slabs
- Retaining walls
- Below-ground structures
- Ground floors
- Pile caps
- Ground beams
- Secant piling
- Contiguous piling
- Sheet piling
- Boundary line construction
- New build waterproofing
Technical Information
- Product Type: Sodium bentonite waterproofing membrane
- Thickness: 6.4mm
- Roll Size: 1.1m × 5m
- Coverage per Roll: 5.5m²
- Hydrostatic Pressure Resistance: 70 metres
- Bentonite Content: 4.88kg/m²
- Peel Adhesion to Concrete: 2.5kN/m
- Low Temperature Flexibility: Unaffected at -32°C
- Installation: Pre-applied
- Suitable for: Concrete foundation structures
- Certification: BBA Approved & CE Marked
Frequently Asked Questions
What is RIW Structureseal used for?
It provides pre-applied waterproofing for below-ground concrete structures including basements, retaining walls, foundation slabs and piling systems.
How does Structureseal work?
Natural sodium bentonite swells when it comes into contact with water, creating a dense waterproof barrier that bonds to the surrounding concrete and helps self-seal small cracks.
Does Structureseal require a primer?
No. Structureseal is installed without primers or adhesives, helping speed up installation.
Can it be installed in wet weather?
Yes. Structureseal is suitable for installation in most weather conditions, including wet and low-temperature environments, provided installation quality is maintained.
Is Structureseal BBA Approved?
Yes. Structureseal holds a BBA Certificate and is suitable for Type A waterproofing systems designed in accordance with BS 8102.
