Ceramic Brushable Blue Epoxy Coating

Ceramic-Filled Abrasion Resistant Epoxy Coating

Ceramic Brushable Blue is a high-performance ceramic-filled epoxy coating designed to provide exceptional protection against abrasion, corrosion, erosion and chemical attack. Reinforced with silicon carbide ceramic fillers, it cures to an ultra-smooth, glass-like finish that helps reduce friction, minimise wear and extend the operational life of industrial equipment and components.

The brushable formulation allows easy application to large surface areas, complex shapes and difficult-to-access equipment. With a generous 90-minute working time, Ceramic Brushable Blue is ideal for industrial maintenance projects where precision and complete coverage are essential.

It can be used as a standalone protective coating or as part of a two-layer wear indicator system with Ceramic Brushable Green. This system allows maintenance teams to visually monitor coating wear and schedule maintenance before equipment damage occurs.

Key Features & Benefits

• Ceramic-filled epoxy coating
• Silicon carbide reinforced formulation
• Exceptional abrasion resistance
• Excellent corrosion protection
• High chemical resistance
• Ultra-smooth glass-like finish
• Helps reduce erosion and cavitation damage
• Minimises pitting and surface wear
• Brush-applied formulation
• Long 90-minute working time
• Suitable for large surface areas
• Wear indicator system compatible
• Temperature resistant up to 150°C
• Easy maintenance monitoring
• Extends equipment service life

Suitable Applications

• Silo protection
• Chute protection
• Mill protection
• Pump refurbishment
• Tank protection
• Metal casting protection
• Impeller blade coating
• Fan blade coating
• Valve protection
• Corrosion protection systems
• Chemical processing equipment
• Industrial machinery maintenance
• Surface restoration projects
• Final protective topcoat applications
• Wear indicator coating systems

Suitable Materials

• Steel
• Cast iron
• Stainless steel
• Aluminium
• Metal castings
• Wood
• Plastics
• Industrial equipment surfaces
• Process plant components

Technical Information

• Product Type: Ceramic-filled epoxy coating
• Filler Type: Silicon carbide ceramic
• Application Method: Brush applied
• Working Time: 90 minutes
• Recommended Coat Thickness: 0.5–1.0mm per coat
• Recommended Coats: Minimum 2
• Recoat Time: 4–8 hours
• Full Cure Time: 24 hours at 22°C
• Temperature Resistance: Up to 150°C
• Finish: Ultra-smooth glass-like surface
• Corrosion Resistance: Excellent
• Chemical Resistance: Excellent
• Abrasion Resistance: Exceptional

Wear Indicator System

For advanced wear monitoring, apply Ceramic Brushable Green as a base coat and Ceramic Brushable Blue as the top coat. As the blue coating gradually wears, the green layer becomes visible, providing a clear indication that recoating is required before the substrate becomes exposed.

Frequently Asked Questions

What is Ceramic Brushable Blue used for?

It is used to protect industrial equipment and surfaces from abrasion, corrosion, erosion, cavitation and chemical attack.

What makes it abrasion resistant?

The coating contains silicon carbide ceramic fillers which provide exceptional wear resistance in harsh industrial environments.

Can it be used as part of a wear monitoring system?

Yes. It can be applied over Ceramic Brushable Green to create a visual wear indicator system that highlights areas of coating wear before equipment damage occurs.

How is it applied?

The coating is brush applied in layers between 0.5mm and 1.0mm thick, with at least two coats recommended for a pinhole-free finish.

How long does it take to cure?

It provides approximately 90 minutes of working time, can be recoated after 4–8 hours and fully cures after 24 hours at 22°C.

What temperature can it withstand?

Once fully cured, Ceramic Brushable Blue is resistant to temperatures up to 150°C.

Downloads

Data Sheet
