Ceramic Brushable Green Epoxy Coating

Ceramic-Filled Abrasion Resistant Epoxy Coating

Ceramic Brushable Green is a high-performance ceramic-filled epoxy coating designed to protect industrial equipment and surfaces from abrasion, corrosion, erosion and chemical attack. Reinforced with silicon carbide ceramic fillers, it cures to an ultra-smooth, glass-like finish that reduces surface friction, minimises wear and extends the operational life of critical assets.

The brushable formulation allows easy application to complex shapes, large surface areas and hard-to-reach equipment. Its long 90-minute working time makes it ideal for larger maintenance projects where careful application and complete coverage are essential.

Ceramic Brushable Green can be used as a standalone protective coating or as part of a wear indicator system when applied over Ceramic Brushable Blue. This layered approach allows maintenance teams to identify high-wear areas before substrate damage occurs, supporting proactive maintenance programmes and reducing downtime.

Key Features & Benefits

• Ceramic-filled epoxy coating
• Silicon carbide reinforced formulation
• Exceptional abrasion resistance
• Excellent corrosion protection
• High chemical resistance
• Ultra-smooth glass-like finish
• Helps reduce erosion and cavitation damage
• Minimises pitting and surface wear
• Brush-applied formulation
• Long 90-minute working time
• Suitable for large surface areas
• Wear indicator system compatible
• Temperature resistant up to 150°C
• Easy maintenance monitoring
• Extends equipment service life

Suitable Applications

• Silo protection
• Chute protection
• Mill protection
• Pump refurbishment
• Tank protection
• Metal casting protection
• Impeller blade coating
• Fan blade coating
• Valve protection
• Corrosion protection systems
• Chemical processing equipment
• Industrial machinery maintenance
• Surface restoration projects
• Final protective topcoat applications
• Wear indicator coating systems

Suitable Materials

• Steel
• Cast iron
• Stainless steel
• Aluminium
• Metal castings
• Wood
• Plastics
• Industrial equipment surfaces
• Process plant components

Technical Information

• Product Type: Ceramic-filled epoxy coating
• Filler Type: Silicon carbide ceramic
• Application Method: Brush applied
• Working Time: 90 minutes
• Recommended Coat Thickness: 0.5–1.0mm per coat
• Recommended Coats: Minimum 2
• Recoat Time: 4–8 hours
• Full Cure Time: 24 hours at 22°C
• Temperature Resistance: Up to 150°C
• Finish: Ultra-smooth glass-like surface
• Corrosion Resistance: Excellent
• Chemical Resistance: Excellent
• Abrasion Resistance: Exceptional

Wear Indicator System

For advanced wear monitoring, apply Ceramic Brushable Blue as a base coat and Ceramic Brushable Green as the top coat. As the green coating gradually wears, the blue layer becomes visible, providing a clear visual indication that maintenance or recoating is required before substrate damage occurs.

Frequently Asked Questions

What is Ceramic Brushable Green used for?

It is used to protect industrial equipment and surfaces from abrasion, corrosion, erosion, cavitation and chemical attack.

What makes it abrasion resistant?

The coating is reinforced with silicon carbide ceramic fillers which provide exceptional wear resistance in demanding industrial environments.

Can it be used as part of a wear monitoring system?

Yes. It can be applied over Ceramic Brushable Blue to create a visual wear indicator system that highlights areas requiring maintenance.

How is it applied?

The coating is brush applied in layers between 0.5mm and 1.0mm thick, with a minimum of two coats recommended.

How long does it take to cure?

It provides approximately 90 minutes of working time, can be recoated after 4–8 hours and fully cures after 24 hours at 22°C.

What temperature can it withstand?

Once cured, Ceramic Brushable Green is resistant to temperatures up to 150°C.

Downloads

Data Sheet
